| processor | Supports 2 fourth-generation Intel® Xeon® Scalable processors, each with up to 60 cores and a maximum power of 350W |
| Memory | Supports up to 32 DDR5 memories, with a maximum speed of 4800MT/s and a maximum memory capacity of 8TB |
| persistent memory | Supports Intel® Optane® persistent memory |
| storage controller | Optional Tri-mode (NVMe/SAS/SATA) HPE Smart Array controller, up to 8GB cache,
supports SATA RAID 0/1/10/5,
supports Intel VROC and HPE smart storage SR100i
optionally comes with 2 M.2 solid-state drives Hot-swappable operating system boot device for raid1 (NS204i-u), optional Micro SD
card |
| storage | Supports up to 30 2.5-inch SATA/SAS hard drives (24 front + 6 rear expansion)
supports up to 16 3.5-inch SATA/SAS hard drives (12 front + 4 rear expansion)
supports up to 36 18 EDSFF 3.S 1T NVMe hard drives or 18 EDSFF 3.S 2T NVMe hard drives,
supporting NVMe U.2, U.3, EDSFF, M.2 solid state drives |
| network | Optional network adapter based on standard PCIe slot
Optional OCP 3.0 network card |
| expansion slot | Standard configuration: 3 PCIe 5.0 slots, supports up to 8 PCIe 5.0 slots,
supports 2 x16 OCP 3.0 slots |
| interface | Optional front display port, optional rear serial port, standard rear VGA
4 USB 3.0 interfaces (1 front, 2 rear, 1 built-in), 3 USB 2.0 interfaces (2 optional, 1 built-in) |
| GPU support | Supports up to 8 single-width GPU cards or 3 double-width GPU cards |
| CD-ROM drive | Support external optical drive |
| manage | Standard iLO standard version,
optional iLO advanced version and OneView advanced version Support HPE iLO 6, SUM, RESTful interface tools
Support mobile application software APP |
| Power and cooling | Optional up to 1600W 1+1 hot-swappable redundant power supply, supporting up to 96% titanium;
supports hot-swappable redundant fans |
| Operating temperature | 5℃-45℃ |
| Chassis size | 2U standard chassis 87.5mm (height) x 448mm (width) x 727mm (depth) (2.5-inch hard drive model)
87.5mm (height) x 448mm (width) x 742.5mm (depth) (3.5-inch hard drive model) |
| Warranty | Channel sales of pre-configured (BTO) models for 3 years, 5×9 next working day response to project sales Configured to order (CTO)
models, 3 years of 7×24×4 service, including basic door-to-door installation services |
